Contex MAGNUM G600

Contex MAGNUM G600
54" Wide Format Scanner


Discontinued

This is a sizable scanner with a sensitive side. Featuring our advanced imaging technology, it's the ultimate choice for your extra-large, full-color scanning and copying needs.

Despite its huge 54” imaging area, the MAGNUM G600 delicately handles oversized drawings, posters, architectural sketches, detailed maps, even fine art – reproducing quality images, fast.

And it’s unbeatable on resolution, delivering the industry’s best at 120,000 pixels. You can rely on the MAGNUM G600 for consistently outstanding extra-wide format scanning results. Expand your business opportunities with Contex’s versatile MAGNUM G600 scanner featuring advanced technology and quality imaging for color and monochrome scanning. The large 54” imaging area is designed to facilitate archival and reprographic tasks with a wide variety of large technical documents, detailed maps and drawings, or color posters and architectural sketches – all at the highest resolution and speed.

You get exceptional professional-grade performance with 508dpi optical resolution with speeds of up to 12 inch/second. With uncompromising image quality standards, the Contex MAGNUM G600 scanner is designed for high-volume productivity for businesses-critical imaging tasks. Whether you are a private business, government or print-for-pay, Contex’s range of HD scanners is the right solution for improved efficiency and productivity.

This is a sizable scanner with a sensitive side. Featuring our advanced imaging technology, it's the ultimate With 508dpi optical resolution, the combination of highly sensitive 4-channel CCD cameras and full-sized high-quality camera lenses, the MAGNUM G600 scanner provide the best image quality available in wide format scanning. With image processing performed inside the scanner, your PC is free to run software applications more efficiently.

Despite its huge 54” imaging area, the Contex MAGNUM G600 delicately handles oversized drawings, posters, architectural sketches, detailed maps, even fine art – reproducing quality images, fast.

And it’s unbeatable on resolution, delivering the industry’s best at 120,000 pixels. You can rely on the Contex MAGNUM G600 for consistently outstanding extra-wide format scanning results.

Image Quality Without Compromise

With 508dpi optical resolution, the combination of highly sensitive 4-channel CCD cameras and full-sized high-quality camera lenses, the MAGNUM G600 scanner provide the best image quality available in wide format scanning. With image processing performed inside the scanner, your PC is free to run software applications more efficiently.

Speed When You Need

The Contex MAGNUM G600 wide format scanner is among the fastest in the business with up to 12 inch/second scanning speeds. Truly a workhorse that can handle very large originals with speed and ease. When you want productivity and reliability, the MAGNUM G600 scanner gives you the best performance and the highest return on your investment.









Order Today!


Contex MAGNUM G600 Scanner
Contex MAGNUM G600 Scanner   Contex MAGNUM G600 Scanner


Contex MAGNUM G600 Scanner Brochure

Other Contex Scanners


54-inch ultra-wide design captures oversized
   documents easily

120,000 pixels (the best in the industry)

Color calibration to sRGB color space

FireWire, USB2 (High Speed)

48-bits Color Data Capture, 16-bits Graytone

Superior color scanning speed of 3 inches per second












CLICK HERE FOR DRIVERS

  Energy Star Certified

  • Specifications
  • Features
  • Accessories
  • In the box
  • Warranty

Model Base Plus
Resolution 600dpi 600dpi
Enhanced resolution 1200dpi 9600 dpi
Maximum Scan Width 54in. (1372mm) 54in. (1372mm)
Maximum Media Width 56in. (1420mm) 56in. (1420mm)
Maximum Media Thickness 0.6in. (15mm) 0.6in. (15mm)
Accuracy 0.1% ± 1 pixel 0.1% +/- 1 pixel
Data Capture (color/mono) 48-bit/16-bit
Color Space NTSC & sRGB
Scanning Speed (inch/sec.)
400dpi (Turbo) 24-bit RGB Color 1.5 3.0
400dpi (Turbo) 8-bit Index Color 3.0 3.0
400dpi (Turbo) 8-bit Grayscale 12.0 12.0
400dpi (Turbo) 1-bit Monochrome 12.0 12.0
Interface
High Speed USB 2.0 with xDTR Yes
Ethernet (LAN) port & Remote HTML Control No
Power, Requirements 110/220/240V, 60/50cs, 180W
Weight / Dimensions (LxWxH) 79 kg (67” x 19” x 7”) (169 x 46 x 18 cm)
Host Platform/Device Drivers Windows and Power Macintosh
Certifications Energy Star, RoHS, UL, CE, GOST-R, CCC


  • FireWire, USB2 (High Speed), STI (Still Image Interface), WIA (Windows Image Acquisition), TWAIN
  • 120,000 pixels and 0.1% +/-1 pixel accuracy
  • 48-bits Color Data Capture, 16-bits Graytone Data Capture, All Digital Cameras
  • Maximum color precision with 48-bit color capture
  • ENERGY SAVER and RoHS Compliant
Software
Description Mfg# Price Cart
Nextimage SCAN
Contex Scanner Software
9691A040 $569.00 Add
Nextimage SCAN+COPY
Contex Scanner Software
9691A057 $1,219.00 Add
Nextimage SCAN+COPY UPGRADE (requires SCAN license installed)
Contex Scanner Software
9691A058 $900.00 Add
JETimageNET Copy Software
Contex Scanner Software
9691A053 $1,617.00 Add
HD Upgrade (BASE to PLUS)
Description Mfg# Price Cart
Upgrade Kit
Contex Scanner Accessory
6799E105 $1,219.00 Add
Floor Stands
Description Mfg# Price Cart
Floor Stand incl. Document Basket for 36" and 42" Scanners
Contex Scanner Accessory
2200D020 $723.00 Add

  • Contex MAGNUM G600
  • 6 ft power cable
  • Drivers
  • User documentation
  • WIDEsystem scan to net software
  • 24 Months Return to Depot Warranty
  • With first six months on-site warranty
  • Scanner Maintenance Software
  • Maintenance Sheet
Standard Warranty: 24 month onsite. Distributor invoiced at time of registration. Must be registered within 30 days of sale.
On-Site Post Warranty
Description Mfg# Price Cart
Third year coverage
(add on to two year standard warranty) at time of scanner purchase
3YR-ADD $1,095.00 Add
Third and Fourth year coverage
(add on to two year standard warranty) at time of scanner purchase
4YR-ADD $1,840.00 Add
Third, Fourth and Fifth year coverage
(add on to two year standard warranty) at time of scanner purchase
5YR-ADD $2,685.00 Add
One year onsite warranty extension
Purchased after the initial scanner order, but before any
pre-existing onsite warranty expires, includes renewals.
EXTEND-ADD $1,295.00 Add
One year onsite post warranty
Use this option for cases where all warranty contracts have
expired and the end-user desires to purchase a onsite warranty.
POST-ADD $1,395.00 Add

For all scanners purchased in the U.S and Canada after July 1, 2002 Contex grants a warranty for 24 months. Parts, which are affected by normal wear and tear (glass plates, white background plates, lamps, belts, rollers), are not covered by any warranty.

In addition Contex offers on-site warranty coverage that may be extended for up to a total of five years. Please contact your local distributor for further information and details.

Help Desk support is also included for immediate answers to software and hardware questions, Monday-Friday 8:00 a.m. to 5:00 p.m., local East to West Coast time by calling (800) 328-5901.

Optional service offerings include: on-site installation services, software and hardware training, a depot repair facility and additional standard time and material service, all at very affordable prices.
