| Optical resolution |
400 dpi |
|
9,600 dpi |
| Scanning speed in 400 dpi turbo |
3.0"/s in 24-bit RGB
3.0"/s in 8-bit index
5.0"/s in graytone and B/W |
| Scan accuracy |
0.1% +- 1 pixel |
| Scan and media width |
Maximum scan width: 18" x 24" (457 x 610 mm) |
| Maximum thickness |
Without top cover: unlimited; with top cover: 1.5" (38 mm) |
| Digital image processing |
Dual 2-D adaptive enhancement and adaptive gray |
Embedded in hardware
|
Color feature extraction, ADL and error diffusion halftoning
2-D sharpening, softening, blur filter and adaptive thresholding |
| iJET technology |
One-touch copy directly to USB or network printer
One-touch scan directly to USB, harddisk or network PC |
Scan modes
|
24-bit color, 8-bit feature extraction/indexed color
8-bit graytone, copy modes with graytones
1-bit B/W, B/W dual 2-D adaptive modes |
| Color adjustment |
3x3 matrix multiplier, independent RGB tone curves (gamma), independent B/W point setting |
| Color space |
NTSC and sRGB |
| Sensors |
4-linear CCD (RGB triplets and panchromatic B/W)
48-bit color data capture, 16-bit graytone data capture, all-digital cameras |
Auto-maintenance system
|
Auto alignment, stitching monitoring and correction, basic and precision color calibration |
| Interface |
Ethernet (LAN) port, High Speed USB 2.0, Remote HTML Control, STI (Still Image Interface), WIA (Windows Image Acquisition), TWAIN |
Weight/dimension/power
|
37 kg, L x W x H (ship) (57" x 30" x 20") (144 x 76 x 50 cm)
110V / 220V / 240V, 60/50 cs, 180W |
System software
|
Included: WIDEsystemNET tools: scanner drivers, maintenance and utilities |
| Host platforms |
Windows XP, Server 2003, Vista (32-bit only) |
- Flatbed design for delicate or thick materials, up to A2 size (18” x 24”)
- Fast 48-bit color, 4-channel CCD imaging
- High-speed monochrome scanning for archiving books, newspapers, and more
- LAN interface and multi-function capabilities with iJET Technology
Software
| Description |
Mfg# |
Price |
Cart |
| Nextimage SCAN
Contex Scanner Software |
9691A040 |
$700.00 |
Add |
| Nextimage SCAN+COPY
Contex Scanner Software |
9691A057 |
$1,500.00 |
Add |
| Nextimage SCAN+COPY UPGRADE (requires SCAN license installed)
Contex Scanner Software |
9691A058 |
$900.00 |
Add |
| JETimageNET Copy Software
Contex Scanner Software |
9691A053 |
$1,950.00 |
Add |
- 6 ft power cable
- Drivers
- User documentation
- WIDEsystem scan to net software
- 24 Months Return to Depot Warranty
- With first six months on-site warranty
- Scanner Maintenance Software
- Maintenance Sheet
Standard Warranty: 24 month onsite. Distributor
invoiced at time of registration. Must be registered within 30 days of sale.
On-Site Post Warranty
| Description |
Mfg# |
Price |
Cart |
| Third year coverage
(add on to two year standard warranty) at time of scanner
purchase |
3YR-ADD |
$1,095.00 |
Add |
| Third and Fourth year coverage
(add on to two year standard warranty) at
time of scanner purchase |
4YR-ADD |
$1,840.00 |
Add |
| Third, Fourth and Fifth year coverage
(add on to two year standard warranty)
at time of scanner
purchase |
5YR-ADD |
$2,685.00 |
Add |
One year onsite warranty extension
Purchased after the initial scanner order,
but before any
pre-existing onsite warranty expires, includes renewals. |
EXTEND-ADD |
$1,295.00 |
Add |
One year onsite post warranty
Use this option for cases where all warranty contracts have
expired
and the end-user desires to purchase a onsite warranty. |
POST-ADD |
$1,395.00 |
Add |
|
